Radios
2.4 GHz 802.11b/g/n/ax client access radio
5 GHz 802.11a/n/ac/ax client access radio
2.4 GHz and 5 GHz dual-band WIDS/WIPS, spectrum analysis, and location analytics radio
2.4 GHz Bluetooth Low Energy radio with Beacon support
Concurrent operation of all four radios
Max aggregate frame rate: 1.7 Gbps
Supported frequency bands (country-specific restrictions apply):
2.412-2.484 GHz
5.150-5.250 GHz (UNII-1)
5.250-5.350 GHz (UNII-2)
5.470-5.600, 5.660-5.725 GHz (UNII-2e)
5.1725-5.825 GHz (UNII-3)
Antenna
Integrated omni-directional antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
Individual antenna elements for each radio
802.11ax, 802.11ac Wave 2, and 802.11n Capabilities
UL/DL-OFDMA, UL-OFDMA, TWT support, BSS coloring
2×2 multiple input, multiple output (MIMO) with 4 spatial streams
SU-MIMO, UL MU-MIMO and DL MU-MIMO support
Maximal ratio combining (MRC) and beamforming
20 and 40 MHz channels (802.11n) 20, 40, and 80 MHz channels (802.11ac Wave 2)
Up to 1024 QAM on both 2.4 GHz and 5 GHz bands
Packet aggregation
Power
Power over Ethernet: 37-47 V (802.af compliant)
Alternative 12 V DC input
Power consumption: 15 W max (802.3af)
Power over Ethernet injector and DC adapter sold separately
Interfaces
1x 10/100/1000 BASE-T Ethernet
1× DC power connector (5.5 mm × 2.5 mm, center positive)
Mounting
All standard mounting hardware included
Desktop, ceiling and wall mount capable
Ceiling tile rail (9/16, 15/16, or 1 1/2" flush or recessed rails), assorted cable junction boxes
Bubble level on mounting cradle for accurate horizontal wall mounting
Physical Security
Two security screw options included
Kensington lock hard point
Concealed mount plate with anti-tamper cable bay
Environment
Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
Humidity: 5 to 95% non-condensing
Physical Dimensions
9.84” x 4.72” x 1.42” (25 cm x 12 cm x 3.6 cm), not including deskmount feet or mount plate
Weight: 17.35 oz (0.5 kg)
Security
Integrated Layer 7 firewall with mobile device policy management
Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
Flexible guest access with device isolation
VLAN tagging (802.1Q) and tunneling with IPSec VPN
PCI compliance reporting
WEP*, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 - Personal, WPA3 - Enterprise, WPA3 - Enhanced Open (OWE)
EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
TKIP and AES encryption
Enterprise Mobility Management (EMM) and Mobile Device Management (MDM) integration
Cisco ISE integration for guest access and BYOD posturing
Quality of Service
Advanced Power Save (U-APSD)
WMM Access Categories with DSCP and 802.1p support
Layer 7 application traffic identification and shaping
Mobility
PMK, OKC, and 802.11r for fast Layer 2 roaming
Distributed or centralized Layer 3 roaming
Analytics
Embedded location analytics reporting and device tracking
Global L7 traffic analytics reporting per network, per device, and per application
Warranty
Lifetime hardware warranty with advanced replacement included
