Specifications
Details
Product code CRS418-8P-8G-2S+RM
Architecture ARM 64bit
CPU IPQ-8072
CPU core count 4
CPU nominal frequency 2208 MHz
Switch chip model 98DX226S
RouterOS license 5
Operating System RouterOS v7
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -20°C to 70°C
IPsec hardware acceleration Yes

Powering
Details
Number of AC inputs 2
AC input range 100-240
Number of PSU slots 2
Frequency (Hz) 50-60
Max power consumption 215 W
Max power consumption without attachments 28 W
Cooling type 4 fans

PoE-out
Details
PoE-out ports Ether1-Ether8
PoE out 802.3af/at
Max out per port output (input 18-30 V) 1.1 A
Max out per port output (input 30-57 V) 0.55 A
Max total out (A) 5.4 A
Total output current 5.4
Total output power 150
Ethernet
Details
10/100/1000 Ethernet ports 17
Number of 1G Ethernet ports with PoE-out 8

Fiber
Details
SFP+ ports 2
Peripherals
Details
Serial console port RJ45
Number of USB ports 1
USB Power Reset Yes
USB slot type USB 3.0 type A
Max USB current (A) 1

Other
Details
CPU temperature monitor Yes
Current Monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes
Certification & Approvals

Details
Certification CE, EAC, ROHS
IP 20
