Specifications
Details
Product code CubeG-5ac60ay
Architecture ARM 32bit
CPU IPQ-4019
CPU core count 4
CPU nominal frequency 448-896 (auto) MHz
Dimensions 115 x 95 x 82 mm
RouterOS license 4
Operating System RouterOS
Size of RAM 256 MB
Storage size 64 MB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C


Powering
Details
Number of DC inputs 1 (PoE-IN)
Max power consumption 10 W
PoE in 802.3af/at
Cooling type Passive
PoE in input Voltage 18-48 V

Wireless specifications
Details
Wireless 5 GHz Max data rate 433 Mbit/s
Wireless 5 GHz number of chains 1
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 11.5
Wireless 5 GHz chip model IPQ4019
Wireless 5 GHz generation Wi-Fi 5

Ethernet
Details
10/100/1000 Ethernet ports 1
Other
Details
GNSS standards GPS

Certification & Approvals
Details
Certification CE, FCC, IC, EAC, ROHS
IP 66
Wireless specifications
5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 22 -93
54MBit/s 18 -74
MCS0 22 -93
MCS7 17 -71
MCS9 15 -68
