Rýchle dvojité Wi-Fi pásmo: Súčasná rýchlosť 450 Mbps na 2,4 GHz a 867 Mbps na 5 GHz, čo spolu dáva rýchlosť Wi-Fi 1317 Mbps.†Integrované do Omada SDN: Zero-Touch Provisioning (ZTP)‡, centralizovaná správa cloudu a inteligentné monitorovanie.
Centralizovaná správa: Prístup do cloudu a aplikácia Omada pre maximálne pohodlie a jednoduchú správu. Plynulý roaming: Ani video streamy a hlasové hovory nie sú ovplyvnené, keď sa používatelia presúvajú medzi lokalitami.
*Podpora PoE: Podpora štandardov 802.3af/at aj pasívneho PoE (PoE adaptér nie je súčasťou balenia) pre flexibilnú inštaláciu. Bezpečná sieť pre hostí: Spolu s viacerými možnosťami overovania (SMS/Facebook Wi-Fi/voucher atď.) a bohatými technológiami bezdrôtovej bezpečnosti.
Pokročilá bezdrôtová technológia: Optimalizujte výkon siete pomocou technológií MU-MIMO, Band Steering, Airtime Fairness a Beamforming.

HARDWARE FEATURES
Interface Gigabit Ethernet (RJ-45) Port×1 (Support IEEE802.3af/at PoE and Passive PoE)
Physical Security Lock Yes
Button Reset
Power Supply • 802.3af/at PoE
• 48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter IS NOT Included)
Power Consumption EU: 9.7W
US: 12.1W
Dimensions ( W x D x H ) 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
Antenna Type 3 Internal Omni
• 2.4 GHz: 4 dBi
• 5 GHz: 5 dBi
Mounting Ceiling /Wall Mounting (Kits included)
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac/n/g/b/a
Frequency 2.4 GHz and 5 GHz
Signal Rate • 5 GHz:Up to 867 Mbps
• 2.4 GHz:Up to 450 Mbps
Wireless Functions • Multiple SSIDs (Up to 15 SSIDs, 8 for 2.4GHz band, 7 for 5GHz band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• Seamless Roaming*
• Omada Mesh*
• Band Steering
• Load Balance
• MU-MIMO
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
Wireless Security • Captive Portal Authentication*
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
Transmission Power • CE:
?20 dBm(2.4 GHz, EIRP)
?23 dBm(5 GHz, EIRP)
• FCC:
?24 dBm(2.4 GHz)
?22 dBm(5 GHz)
MANAGEMENT
Omada App Yes
Centralized Management • Omada Hardware Controller OC300
• Omada Hardware Controller OC200
• Omada Software Controller
• Omada Cloud-Based Controller
Cloud Access Yes, through
• OC300
• OC200
• Omada Software Controller
• Omada Cloud-Based Controller
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1,v2c
System Logging Local/Remote Syslog Local/Remote Syslog
SSH Yes
Web-based Management HTTP/HTTPS
L3 Management Yes
Multi-site Management Yes
Management VLAN Yes
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller
OTHERS
Certification CE, FCC, RoHS
Package Contents • AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP223
• Mounting Kits
• Installation Guide
System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment • Operating Temperature: 0–40 ? (32–104 ?)
• Storage Temperature: -40–70 ? (-40–158 ?)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
