Technical Specifications
Overview
Dimensions
?147 x 65.5
(?5.8 x 2.6")
IR Night Vision
15m (50 ft)
Smart IR (4x controllable zones)
Face Recognition
No
License Plate Recognition
No
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
12MP
Field of View
H: 180°, V: 180°, D: 180°
Audio
Two-way audio
Weatherproofing
IP66
Tamper Resistance
IK10
Mounting
Surface Mount (Included)
AI 360 Junction Box, Camera Dual Mount, Arm Mount (Optional)
UniFi Application Suite
Protect
Yes
Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
24 FPS
Resolution
12MP 3504 x 3504 (1:1)
Optics
Sensor
1/1.6" 12MP
Lens
Fisheye lens
Night Mode
Built-in IR LED illumination and IR cut filter
Hardware
Max. Power Consumption
7.14W
Supported Voltage Range
37—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
610 g (1.3 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Mount Material
Polycarbonate
Expansion Slot
MicroSD card
Button
(1) Factory reset
Ambient Operating Temperature
-30 to 50o C (-22 to 122o F)
Ambient Operating Humidity
0 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
