Technical Specifications Network Video Recorder Instant Dimensions 220 x 220 x 47 mm (8.7 x 8.7 x 1.9") UniFi Application Suite Protect Yes Access Yes Managed Cameras (15) HD (8) 2K (6) 4K Managed Access Hubs 50 Storage Capacity (1) 3.5" drive bay Data Protection Yes Vantage Point Yes Networking Interface (1) GbE RJ45 uplink port (6) GbE PoE RJ45 downlink ports (1) HDMI port (Viewport) Form Factor Compact Desktop Mounting Wall, Din rail mount (Included) Door Access Support Yes Hard Drive Capacity (1) 3.5" HDD support Max. Power Budget for Drives 11W Max. Power Consumption 9W Power Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 Hz Power Supply AC/DC, Internal, 60W PoE Budget 40W Max. PoE Wattage per Port by PSE PoE 15.4W Voltage Range PoE Mode 44–57V Processor Quad-core ARM® Cortex®-A55 at 1.7 GHz Memory 4 GB Management Ethernet Bluetooth Display 1.14" screen Weight 1.04 kg (2.3 lb) Enclosure Materials Polycarbonate Mount Material Polycarbonate LEDs Ethernet Yes PoE Yes Ambient Operating Temperature 0 to 40° C (32 to 104° F) Ambient Operating Humidity 5 to 95% noncondensing NDAA Compliant Yes Certifications FCC, IC, CE, Electrical Safety G5 Turret Ultra Dimensions O90 x 71.2 mm (O3.5 x 2.8") IR Night Vision 30 m (98 ft) Smart Detections (People, Vehicles, Animals) Yes Resolution 2K Field of View H: 102.4°, V: 54.9°, D: 120.6° Audio Microphone Weatherproofing IP66 Tamper Resistance IK04 Mounting Wall, ceiling mount (Included) Junction box, arm mount (Optional) Networking Interface 10/100 MbE RJ45 port Video Image Settings Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay Max. Frame Rate 30 FPS Resolution 4MP 2688 x 1512 (16:9) Optics Sensor 1/2.4" CMOS Lens Fixed focal length Night Mode Built-in IR LED illumination and IR cut filter Max. Power Consumption 4W Supported Voltage Range 37—57V DC Power Method PoE Processor Dual-core Arm® Cortex®-A7 based chip Weight 330 g (11.6 oz) Enclosure Material Aluminum alloy, UV-stabilized polycarbonate Mount Material Polycarbonate Button (1) Factory-reset Cable Cable Connector Type RJ45 Cable Diameter 5 mm (0.2") Cable Length 30 cm (1 ft) Jacket Material Polycarbonate Jacket Enclosure Dimensions O20 x 70.6 mm (0.8 x 2.8") Jacket Enclosure Material Thermoplastic elastomer, polycarbonate, silicone rubber Ambient Operating Temperature -30 to 50° C (-22 to 122° F) Ambient Operating Humidity 0 to 90% noncondensing NDAA Compliant Yes Certifications CE, FCC, IC HDD Dimensions 147 x 101.6 x 26.1 mm (5.75 x 4 x 1") Hard Disk Form Factor 3.5-inch Weight 0.45 kg (0.99 lb) Storage Capacity 1 TB Power Method 5V/12V input Management Interface SATA 6 Gb/s Rotation Speed 5400 RPM Workload Rating 180 TB/year Mean Time Between Failure (MTBF) 1,000,000 h Ambient Operating Temperature 0 to 65° C (32 to 149° F) Ambient Operating Humidity 5 to 95% noncondensing NDAA Compliant Yes Certifications FCC, CE, TUV, RCM, KC, BSMI
