Overview
Dimensions
136 x 64 x 92 mm
(5.6 x 2.5 x 3.6")
IR Night Vision
20 m (65 ft)
Face Recognition
?
License Plate Recognition
?
Smart Detections (People, Vehicles, Animals)
?
Resolution
Dual 4K
Field of View
H: 180°, V: 56.7°
Audio
Two-way audio
Weatherproofing
IP66
Tamper Resistance
IK04
Mounting
Ceiling, Pole, Wedge Mount, Pan Adapter
(Included)
Camera Junction Box, Arm mount, Dual Mount, Gang Box Mounting Plate (Optional)
UniFi Application Suite
Protect
?

Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
20 FPS
Resolution
16MP 7680 x 2160 (3.5:1)
Optics
Sensor
Dual 1/1.8" 8MP
Lens
(2) Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter

Hardware
Max. Power Consumption
15W
Supported Voltage Range
37—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
839 g (1.8 lb)
Enclosure Material
Aluminum alloy, polycarbonate
Mount Material
Polycarbonate, stainless steel
Expansion Slot
MicroSD card
Button
(1) Factory reset
Ambient Operating Temperature
-20 to 50o C (-4 to 122o F)
Ambient Operating Humidity
0 to 90% noncondensing
NDAA Compliant
?
Certifications
CE, FCC, IC
