Základní popis
Doba prevádzky pre zaťaženie
900
W
Min-max: 90-900 W
3min 12s
Max. použitá kapacita
100 %
Main input voltage
230 V AC 1 fáz.
Other input voltage
220 V
240 V
Input connection
IEC 60320 C14
Efficiency at full load
110...285 V 40% load
180...285 V plná zátěž
Input frequency
40...70 Hz aut. detekcia
Output voltage
230 V AC 1 fáz.
Other output voltage
220 V
240 V
Rated power in W
900 W
Rated power in VA
1000 VA
Output connection
3 IEC 60320 C13
Bypass type
Vnútorné premostenie (automatické a manuálne)
Crest factor
3 : 1
Harmonic distortion
3 %
Maximum configurable power in VA
1000 VA
Maximum configurable power in W
900 W
UPS topology
On-Line
Waveform type
Sínusoida
Efficiency
88 % (plná zátěž)
Output frequency
50/60 Hz +/- 3 Hz synchronizovaná so sieťou
Vymeniteľné batérie
APCRBCV200
Grafy
Doba prevádzky
View Runtime Graph
Účinnosť
View Efficiency Graph
Doplňky
Additional information
Konfigurovateľné na 220: Menovité výstupné napätie 230 alebo 240
Battery type
Lead-acid internal included
Control panel
Multifunkčná lcd stavová a riadiaca konzola
Free slot
1
Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
UPS connectivity
Serial port
USB port
Available expansion slot
Surge energy rating
945 J
Number of rack unit
2U
Cable length
1,5 m
Number of cables
1
Color
Čierna (RAL 7010)
Height
86 mm
Width
438 mm
Depth
312 mm
Product weight
11,5 kg
Mounting location
Column : Value (Slovak) missing
Mounting preference
Lower
Mounting mode
Montáž na rám
USB compatible
Yes
Mounting position
Vodorovná
Mounting mode
Montáž na rám with included kit
Max runtime
3 min
