CPU Intel® Socket LGA4710-2 for Xeon® 600 Processors for Workstation Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** * Refer to https://www.asus.com/support/download-center/ for CPU support list. ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.  Chipset Intel® W890 Chipset Memory 8 x DIMM slots, DDR5, ECC Registered DIMM (RDIMM), 3DS-RDIMM, and Multiplexed Combined Rank DIMM (MRDIMM)* 8-channel memory architecture Supports Intel® Extreme Memory Profile (XMP) memory module * Only channels A, C, E, and G will function when an Intel® Xeon® 630 Series Processor is in use. ** Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market. Graphics 1 x VGA port from AST2600 2 x USB 40Gbps (USB4®) ports support USB Type-C® display outputs* * Supports max. 8K@60Hz as specified in DisplayPort 1.4. "** Output at USB4® Type-C® 40G USB 1 or USB4® Type-C® 40G USB 2 ports, each requires a Mini DisplayPort IN to DisplayPort adapter cable. For more information on display connection and video output configuration using the Mini DisplayPort IN ports, please refer to the user manual." *** The display function of the Type-C® port depends on the resolution supported by your processor or graphics card. For more details, please refer to the product manual. Expansion Slots Intel® Xeon® 690/670/650 Series Processors* 7 x PCIe 5.0 slot(s) (Seven at x16/x16/x16/x16/x16/x8/x16)** Intel® Xeon® 630 Series Processor* 7 x PCIe 5.0 slot(s) (Seven at x16/x0/x16/x0/x16/x0/x16)** * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/). * Specifications vary by CPU types. ** Please refer to the block diagrams in the Appendix for more details. *** CXL (Compute Express Link) is only supported in PCIEX16(G5)_1, PCIEX16(G5)_3, PCIEX16(G5)_5, and PCIEX16(G5)_7 - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals. Storage Total supports 4 x M.2 slots, 2 x SlimSAS ports, 1 x MCIO connector, and 4 x SATA 6Gb/s ports* Intel® Xeon® 690/670/650 Series Processors** M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) MCIO connector (supports PCIe 5.0 x8, and runs at x4/x4) Intel® Xeon® 630 Series Processor** M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) Intel® W890 Chipset* 2 x SlimSAS ports that support PCIe 4.0 x4 mode NVMe device 4 x SATA 6Gb/s ports * Specifications vary by CPU types. ** Supports Intel® Virtual RAID on CPU (Intel® VROC) and Intel Volume Management Device (Intel®VMD) *** Intel® VROC Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. VROC_HW_Key is purchased separately. Ethernet 1 x Intel® dual 10Gb Ethernet 1 x Realtek 1Gb Ethernet* ASUS LANGuard * This dedicated LAN port is for BMC and IPMI connections only; internet access is not supported. Wireless & Bluetooth® "M.2 slot only (Key E, CNVi & PCIe)* * Wi-Fi module is sold separately." USB Rear USB (Total 8 ports) 2 x USB4® (40Gbps) port(s) (2 x USB Type-C®) 6 x USB 10Gbps port(s) (6 x Type-A) Front USB (Total 7 ports) 1 x USB 20Gbps connector (supports USB Type-C®) 1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports * USB Type-C® power delivery output: max. 5V/3A Audio "Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC* - Impedance sense for front and rear headphone outputs - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) - Supports up to 32-Bit/192 kHz playback*" Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers - Unique de-pop circuit * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. Back Panel I/O Ports 2 x USB4® (40Gbps) (2 x USB Type-C®) 6 x USB 10Gbps port(s) (6 x Type-A) 1 x VGA port 2 x Mini DisplayPort IN 2 x Intel® dual 10Gb Ethernet ports 1 x Realtek 1Gb Ethernet (Dedicated management LAN for AST2600) 2 x Audio jacks  1 x BIOS FlashBack™ button  1 x Clear CMOS button  Internal I/O Connectors Fan and Cooling Related 1 x 4-pin CPU Fan header(s) 1 x 4-pin CPU OPT Fan header(s) 5 x 4-pin Chassis Fan header(s) 1 x W_PUMP+ header(s) 2 x 4-pin VRM Fan header (with one of the VRM fans onboard) 1 x 4-pin M.2 Fan header (with M.2 FAN onboard) Power Related 1 x 24-pin Main Power connector 1 x 4-pin to 24-pin Main Power connectors 2 x 8-pin +12V CPU Power connector 2 x 8-pin PCIe to CPU power connectors 2 x 8-pin PCIe Power connector Storage Related 4 x M.2 slots (Key M) 1 x MCIO connector 4 x SATA 6Gb/s ports 2 x SlimSAS connector USB 1 x USB 20Gbps connector (support(s) USB Type-C® ) 1 x USB 5Gbps header(s) support(s) 2 additional USB 5Gbps ports 2 x USB 2.0 header(s) support(s) 4 additional USB 2.0 ports Miscellaneous 2 x Addressable RGB Gen 2 header(s) 1 x Chassis Intrusion header 1 x COM Port header 1 x CPU Over voltage jumper 1 x Reset(FlexKey) button 1 x Front Panel Audio header (F_AUDIO) 1 x LN2 Mode jumper 1 x M.2 slot (Key E) 7 x Probelt measurement points 1 x ReTry button 3 x RSVD header(s)/switch(s) 1 x Safe Boot button 1 x Slow Mode switch 1 x Start button 1 x 10-1 pin Front Panel System header 1 x RTC Battery header 1 x VROC key header 1 x Thermal Sensor header Special Features ASUS 5X PROTECTION III - DIGI+ VRM (- Digital power design with DrMOS) - ESD Guards - LANGuard - Overvoltage protection - SafeSlot - Stainless-steel back I/O ASUS Q-Design - M.2 Q-Latch - M.2 Q-Release - M.2 Q-Slide - PCIe Slot Q-Release Slim (with PCIe SafeSlot) - Q-Code - Q-Connector - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - Steel backplate - VRM heatsink design - Fan-based active cooling design for VRM and M.2 heatsinks ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Clear CMOS button - Dual DIMM clips - ProCool II - Pre-mounted I/O shield - SafeDIMM Aura Sync - Addressable RGB Gen 2 header(s) Bespoke Motherboard Design & Business Focused Features - 24/7 reliability - Overcurrent protection Software Features ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Xpert 4 ASUS DriverHub - ASUS CPU-Z Adobe Creative Cloud (Free Trial)** Norton 360 Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUSTeK. EzFlash Utility FlexKey * For more software features, please visit the asus support site or refer to www.asus.com/support for additional information. ** For detailed information on the supported models and restricted regions for this redemption offer, please refer to https://www.asus.com/content/asus-offers-adobe-creative-cloud/. Remote Management Features IT Management software supported - ASUS Control Center Express(ACCE) BMC Related 1 x BMC switch 1 x BMC LAN fixed IP switch 1 x Message LED header 1 x microSD card socket 2 x LAN LED header(s) 1 x Location LED header 1 x Location button header 1 x PSU_SMB header 1 x SMART_PSU switch 1 x VGA switch 1 x VPP_I2C header BMC LED Design - 1 x BMC LED - 1 x Message LED - 1 x Location LED - 1 x Location button LED BIOS 512 Mb Flash ROM, UEFI AMI BIOS(text-based) Manageability WOL by PME, PXE Accessories Cables 2 x SATA 6Gb/s cables 1 x Thermistor cable pack 1 x 4-pin to 24-pin adapter cable for ATX power connector Additional Cooling Kit 1 x AngleBoost Fan Kit 2 x Thermal pad for M.2 22110 Miscellaneous 1 x Q-connector 1 x M.2 Q-Latch package(s) 1 x Screw package for M.2 Key E 1 x AMI license sticker 1 x M.2 backplate rubber package(s) 1 x E2A CPU carrier (for Intel® Xeon® 690 Series Processors) 1 x E2B CPU carrier (for Intel® Xeon® 670/650/630 Series Processors) Documentation 1 x ACC Express activation key card 1 x Quick start guide Operating System Windows 11 Form Factor EEB Form Factor 12 inch x 13 inch (30.5 cm x 33 cm)
