Camera
Camera Case Type
Turret
Image Sensor
1/2.4" Progressive Scan CMOS
Shutter Speed
1/3 s to 1/100,000 s
Day &Night
IR cut filter
WDR
120 dB WDR
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Protection Level
IP67
Material
Metal
Wi-Fi Support
No
Camera/General
Power Supply
12VDC ± 25%, 0.41A, 5W MAX

PoE(IEEE 802.3af class 3), 6.5W MAX

Working Temperature
-30 °C to 60 °C (-22 °F to 140 °F)
Working Humidity
95% or less (non-condensing)
Dimension (W × D × H)
O127.3 mm × 96.3 mm (O5" × 3.8")
Approx. 590 g (1.3 lb.)
Camera/Lens
Focal Length
2.8 mm
Aperture
F1.6
Focus
Fixed
FOV
horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°
Lens Mount
M12
Camera/Compression Standard
Video Compression
Main stream: H.265+/H.264+/H.265/H.264

Sub-stream: H.265/H.264/MJPEG

H.264 Type
Main Profile/High Profile/Baseline Profile
H.264+
Main Profile
H.265 Type
Main Profile
H.265+
Main Profile
Video Bit Rate
32 Kbps to 16 Mbps
Camera/Image
Main Stream
50 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz: 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Image Setting
Mirror, rotate, saturation, brightness, contrast, sharpness, gain, white balance

adjustable by client software or web browser

Day/Night Switch
Auto/Scheduled/Day/Night
Camera/Network
Alarm Trigger
Motion detection (support alarm triggering by specified target types (person and vehicle)), video tampering alarm, exception
Protocols
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6,

UDP, QoS, Bonjour, FTP, 802.1x, SMTP

General Function
Anti-flicker, heartbeat, password protection, password reset via email
Client
HiLook
Camera/Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
N/A
Audio I/O
No
Video Out
No
Alarm I/O
No
Reset Button
No
Camera/Illuminator
Supplement Light Type
IR and White Light
Supplement Light Range
Up to 30 m
NVR/Video and Audio
IP Video Input
8-ch
Incoming/Outgoing Bandwidth
80 Mbps/80 Mbps
HDMI/VGA Output
HDMI:4K(4096x2160)/30Hz,4K(3840*2160)/30Hz, 2K(2560×1440)/60Hz

1920*1080/60Hz,1600*1200/60Hz,1280*1024/60Hz,1280*720/60Hz

VGA:1920*1080/60Hz,1280*1024/60Hz,1280*720/60Hz

NVR/Decoding
Decoding Format
H.265+;H.265;H.264+;H.264
Capability
1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
NVR/Network
Network Interface
1, RJ45 10/100M Ethernet interface
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,

UPnP™, HTTP, HTTPS

Remote Connection
32
NVR/PoE
Interface
8-ch
Power
? 75 W
Standard
IEEE 802.3 af/at
NVR/Auxiliary Interface
SATA
1
Capacity
Up to 8 TB capacity for each disk
USB Interface
Rear panel: 2 × USB 2.0
Alarm In/Out
No
NVR/General
Power Supply
48 VDC
Consumption (without HDD and PoE off)
? 10 W (without HDD and PoE off)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
265 × 225 × 48 mm (10.4" × 8.9" × 1.9")
Weight (without hard disk)
? 1 kg (2.2 lb)
Kit
Accessories
4 network cables, 1 HDMI cable
Hard Drive
Pre-installed 2 TB HDD
Certification
CE
Weight (with package)
? 7.5 kg (16.5 lb)
Decoding
Recording resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback
8-ch
