Motion Detection 2.0
Human/Vehicle Analysis
1-ch
Video and Audio
IP Video Input
4-ch
Incoming Bandwidth
40 Mbps
Outgoing Bandwidth
80 Mbps
HDMI Output
1-ch,4K(4096x2160)/30Hz,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz,1080P(1920×1080)/60Hz,UXGA(1600×1200)/60Hz,SXGA(1280×1024)/60Hz,720P(1280×720)/60Hz
VGA Output
1-ch, 1080P(1920×1080)/60Hz,UXGA(1600×1200)/60Hz,SXGA(1280×1024)/60Hz,720P(1280×720)/60Hz
Video Output Mode
HDMI/VGA simultaneous output
Audio Output
1-ch, RCA (Linear, 1 K?)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1k?)
Decoding
Decoding Format
H.265+,H.265,H.264+,H.264,MPEG4
Recording Resolution
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Decoding Capability
AI&4K Off: 8-ch@1080p(30fps)

AI/4K On: 6-ch@1080p(30fps)

*: The length or width of camera resolution (each track) cannot exceed 4096 pixels

Synchronous playback
4-ch
Network
Remote Connection
32
Network Protocol
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface
PoE
Interface
4-ch, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
? 50 W
Standard
IEEE 802.3 af/at
Auxiliary Interface
SATA
1
Capacity
Up to 8TB capacity for each disk
USB Interface
2 × USB 2.0
General
Power Supply
48 VDC or ? 65W
Consumption
? 10 W (without enabling PoE)
Working Temperature
-10 to +55° C (14 to 131° F)
Working Humidity
10 to 90 %
Chassis
1U
Dimension (W × D × H)
263× 223 × 48 mm (10.34" × 8.76" × 1.9")
? 1.5 kg (3.3 lb)
Certification
CE
55032/55035/61000-3-2/61000-3-3/50130-4
