Camera
Image Sensor
1/2.9" Progressive Scan CMOS
Max. Resolution
2560 × 1440
Min. Illumination
Color: 0.01 Lux @ (F1.6, AGC ON),B/W: 0.005 Lux @ (F1.6, AGC ON),0 Lux with IR
Lens
Focal Length
2.8 mm, 4 mm
FOV
2.8 mm,horizontal FOV 91°, vertical FOV 49°, diagonal FOV 108°

4 mm, horizontal FOV 74°, vertical FOV 40°, diagonal FOV 87°

Aperture
F1.6
Illuminator
Supplement Light Type
IR
Supplement Light Range
IR distance: up to 30 m
IR Wavelength
850 nm
PTZ
Movement Range (Pan)
0° to 345°
Movement Range (Tilt)
0° to 80°
Pan Speed
Up to 25°/s
Tilt Speed
Up to 20°/s
Video
Main Stream
50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream
50 Hz: 25 fps (1280 × 720, 768 × 432, 512 × 288)

60 Hz: 30 fps (1280 × 720, 768 × 432, 512 × 288)

Video Compression
Main stream: H.265/H.264,

Sub-stream: H.265/H.264

Video Bit Rate
256 Kbps to 2 Mbps
H.264 Type
Baseline profile,Main profile,High profile
H.265 Type
Main profile
Audio
Audio Compression
G.711,AAC-LC
Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw), 16 to 64 Kbps (AAC-LC)
Audio Sampling Rate
8 kHz,16 kHz
Environment Noise Filtering
Yes
Network
Protocols
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,UPnP,IGMP,QoS,IPv4,IPv6,UDP,Bonjour,SSL/TLS
API
ONVIF, SDK
Security
Password protection,HTTPS encryption,security audit log,basic and digest authentication for HTTP/HTTPS,TLS 1.1/1.2, WSSE for Open Network Video Interface
Client
iVMS-4200, HiLookVision, Hik-Partner-Pro
Wireless (Wi-Fi)
Encryption Mode
WPA-PSK/WPA2-PSK
Wi-Fi Protocols
IEEE802.11b,IEEE802.11g,IEEE802.11n
Frequency Range
2.412 GHz to 2.472 GHz
Channel Bandwidth
20 MHz
Modulation
802.11b: CCK, QPSK, BPSK,

802.11g: OFDM,

802.11n: OFDM

Transfer Rate
11b: up to 54 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps
Wireless Range
Up to 50 m

(The performance varies based on actual environment)

Image Settings
Saturation, brightness, contrast, and sharpness adjustable by client software
Wide Dynamic Range (WDR)
Digital WDR
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone
1 built-in microphone
On-board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Speaker
1 built-in speaker
Event
Basic Event
Motion detection (support alarm triggering by specified target type (human and vehicle)), exception
Linkage
Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite
General
Power
12 VDC ± 10%, 1 A, max. 10 W, O2 mm coaxial power plug, reverse polarity protection
Dimension
163.9 mm × 185.8 mm × 131.9 mm (6.45" × 7.31" × 5.19")
Camera weight: 565 g (1.25 lb.) With package weight: 1020 g (2.25 lb.)
Material
Plastic
Operating Condition
-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
General Function
heartbeat,mirror
Approval
EMC
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)
Safety
CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
Environment
CE-RoHS (2011/65/EU),WEEE (2012/19/EU)
Protection
IP66 (IEC 60529-2013)
