Door station/Video parameters
Resolution
1920 × 1080

Stream resolution: 960 × 576

Lens
1/2.7" CMOS
FOV
Horizontal: 66.2°,Vertical: 37.2°
Door station/Audio parameters
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Door station/Device interfaces
I/O output
1 relay output
Four-wire
1 four-wire interface (1-ch video input, 1-ch audio input/output, 1-ch power,supply, 1-ch grounding)
Door station/General
Power supply
12 VDC
Power consumption
Max. 5W
Working temperature
-10° C to + 55° C (14° F to 131° F)
Working humidity
10% to 90%
Dimensions
128 mm × 42 mm × 24.8 mm
Indoor station/Display parameters
Operation method
Physical button
Type
7-inch colorful TFT LCD
Resolution
800 × 480
Indoor station/Audio parameters
Audio input
Built-in omnidirectional microphone
Audio output
Built-in loudspeaker
Audio quality
Noise suppression and echo cancellation
Indoor station/General
Power supply
12 VDC
Power consumption
?5 W
Working temperature
-10° C to + 55° C (14° F to 131° F)
Working humidity
10% to 90%
Dimensions (W × H × D)
195.8 mm × 132.8 mm × 18.39 mm (7.7" × 5.2" ×0.7")
