Specifications
Product code
S53UG+5HaxD2HaxD-TC&RG650E-EU
Suggested price
$349.00
Architecture
ARM 64bit
CPU
IPQ-6010
CPU core count
4
CPU nominal frequency
864-1800 MHz
CPU Threads count
4
Switch chip model
IPQ-6010
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-40°C to 70°C
Powering
Number of DC inputs
1 (DC jack)
DC jack input Voltage
12-28 V
Max power consumption
27 W
Max power consumption without attachments
18 W
Cooling type
Passive
Mobile
3G Category
R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
3G bands
1 (2100MHz)
5 (850MHz)
8 (900MHz)
LTE Category
20 (2.0 Gbps Downlink, 211 Mbps Uplink)
MIMO DL
4x4
MIMO UL
1x1 (5G SA MIMO UL 2x2)
LTE FDD bands
1 (2100MHz)
3 (1800MHz)
5 (850MHz)
7 (2600MHz)
8 (900 MHz)
20 (800MHz)
28 (700MHz)
32 (1500 MHz)
LTE TDD bands
38 (2600MHz)
41 (2500MHz)
42 (3500MHz)
40 (2300MHz)
43 (3700MHz)
5G NSA FDD bands
1 (2100 MHz)
3 (1800 MHz)
5 (850 MHz)
7 (2600 MHz)
8 (900 MHz)
20 (800 MHz)
26 (850 MHz)
28 (700 MHz)
67 (700 MHz)
75 (1500 MHz)
76 (1500 MHz)
5G NSA TDD bands
38 (2600 MHz)
40 (2300 MHz)
41 (2500 MHz)
77 (3700 MHz)
78 (3500 MHz)
5G SA FDD bands
1 (2100 MHz)
3 (1800 MHz)
5 (850 MHz)
7 (2600 MHz)
8 (900 MHz)
20 (800 MHz)
26 (850 MHz)
28 (700 MHz)
67 (700 MHz)
75 (1500 MHz)
76 (1500 MHz)
5G SA TDD bands
38 (2600 MHz)
40 (2300 MHz)
41 (2500 MHz)
77 (3700 MHz)
78 (3500 MHz)
TAC
86896506
Wireless specifications
Wireless 2.4 GHz Max data rate
574 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz
3
Wireless 2.4 GHz chip model
QCN-5022
Wireless 2.4 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
1200 Mbit/s
Wireless 5 GHz Number of chains
2
Wireless 5 GHz standards
802.11a/n/ac/ax
Antenna gain dBi for 5 GHz
6
Wireless 5 GHz chip model
QCN-5052
Wireless 5 GHz generation
Wi-Fi 6
Ethernet
10/100/1000 Ethernet ports
4
Number of 2.5G Ethernet ports
1
Peripherals
Number of SIM slots
1 Modem (Micro SIM)
Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB type A
Max USB current (A)
1.5
Other
CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Mode button
Yes
eSIM
Yes
Certification & Approvals
Certification
CE, EAC, ROHS
IP
20
