Specifications
Product code
CRS418-8P-8G-2S+5axQ2axQ-RM

Architecture
ARM 64bit
CPU
IPQ-8072A
CPU core count
4
CPU nominal frequency
2208 MHz
CPU Threads count
4
Switch chip model
98DX226S
RouterOS license
5
Operating System
RouterOS v7
Size of RAM
1 GB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-20°C to 70°C

Powering
Number of AC inputs
2
AC input range
100-240
Number of PSU slots
2
Frequency (Hz)
50-60
Max power consumption
227 W
Max power consumption without attachments
43 W
Cooling type
4 fans

PoE-out
PoE-out ports
Ether9-Ether16
PoE out
802.3af/at
Low voltage PoE-Out current limit
1.1 A
High voltage PoE-Out current limit
0.56 A
Total output power
150

Wireless specifications
Wireless 2.4 GHz Max data rate
1148 Mbit/s
Wireless 2.4 GHz Number of chains
4
Wireless 2.4 GHz standards
802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz
5
Wireless 2.4 GHz chip model
QCN-5024
Wireless 2.4 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
2400 Mbit/s
Wireless 5 GHz Number of chains
4
Wireless 5 GHz standards
802.11a/n/ac/ax
Antenna gain dBi for 5 GHz
6
Wireless 5 GHz chip model
QCN-5054
Wireless 5 GHz generation
Wi-Fi 6

Ethernet
10/100/1000 Ethernet ports
17
Number of 1G Ethernet ports with PoE-out
8

Fiber
SFP+ ports
2

Peripherals
Serial console port
RJ45
Number of USB ports
1
USB Power Reset
Yes
USB slot type
USB 3.0 type A
Max USB current (A)
1

Other
CPU temperature monitor
Yes
Current Monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Mode button
Yes

Certification & Approvals
Certification
CE, FCC, IC, EAC, ROHS
IP
20
