Specifications
Product code
CRS812-8DS-2DQ-2DDQ-RM

Architecture
ARM 64bit
CPU
AL52400
CPU core count
4
CPU nominal frequency
2000 MHz
CPU Threads count
4
Switch chip model
98DX7335
RouterOS license
6
Operating System
RouterOS v7
Size of RAM
4 GB
Storage size
512 MB
Storage type
NAND
MTBF
Approximately 200'000 hours at 25C
Tested ambient temperature
-10°C to 50°C

Powering
Number of AC inputs
2
AC input range
100-240
Number of PSU slots
2
Frequency (Hz)
50-60
Max power consumption
134 W
Max power consumption without attachments
81 W
Cooling type
4 fans

Ethernet
Number of 1G/2.5G/5G/10G Ethernet ports
2 (supported: 10M/100M/1G/10G)
Number of 50G SFP56 ports
8
Number of 200G QSFP56 ports
2
Number of 400G QSFP56-DD ports
2

Peripherals
Serial console port
RJ45

Other
CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes

Certification & Approvals
Certification
CE, EAC, ROHS
IP
20
