Specifications
Architecture
ARM 32bit
CPU
AN7563PT
CPU core count
2
CPU nominal frequency
950 MHz
CPU Threads count
2
Switch chip model
AN7563PT
RouterOS license
4
Operating System
RouterOS v7
Size of RAM
512 MB
Storage size
128 MB
Storage type
NAND
MTBF
Approximately 100'000 hours at 25C
Tested ambient temperature
-40°C to 50°C

Wireless capabilities
Wireless 2.4 GHz Max data rate
688 Mbit/s
Wireless 2.4 GHz Number of chains
2
Wireless 2.4 GHz standards
802.11b/g/n/ax/be
Antenna gain dBi for 2.4 GHz
4.4
Wireless 2.4 GHz chip model
MT7991
Wireless 2.4 GHz generation
Wi-Fi 7
Wireless 5 GHz Max data rate
2882 Mbit/s
Wireless 5 GHz Number of chains
3
Wireless 5 GHz standards
802.11a/n/ac/ax/be
Antenna gain dBi for 5 GHz
7
Wireless 5 GHz chip model
MT7991
Wireless 5 GHz generation
Wi-Fi 7
WiFi speed
BE3600

Ethernet
10/100/1000 Ethernet ports
3
Number of 2.5G Ethernet ports
1

Powering
Number of DC inputs
1 (USB-C)
Max power consumption
12 W
Cooling type
Passive
USB C input Voltage
5 V
Certification & Approvals

Certification
CE, FCC, IC, EAC, ROHS
IP
20

Other
CPU temperature monitor
Yes

Included parts
5 V 2.4 A power adapter (black)
