SPECIFICATION Graphics Engine RX 7600 8G-L/OC Video Memory 8GB GDDR6 Stream Processor 2048 Units Engine Clock(OC) up to 2280MHz(Game) up to 2695MHz(Boost) Engine Clock(STD/Silent) up to 2250MHz(Game) up to 2655MHz(Boost) Memory Clock 18.0 Gbps Memory Interface 128-bit DirectX® Support 12 Bus Standard PCIE 4.0 Standard Display Connectors 1 x HDMI 2.1,3 x DisplayPort 2.1 (only 2x simultaneous DP2.1 connections can be supported) Customized Specifications Product Remark 'Game Clock' is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. 'Boost Clock' is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to:thermal conditions and variation in applications and workloads. Feature Support OpenGL Support AMD Stream Technology Support AMD Eyefinity Technology Support AMD Smart Access Memory Support For more infromation, please refer AMD Website. Maximum Resolution VGA DVI DisplayPort 4096x2160 HDMI 4096x2160 Power Specs + Board Dimensions Board Dimensions 223mm*132mm*45mm 234mm*149mm*45mm(with bracket) Minimum System Power requirement (W) 600W Extension Power Connector One 8-Pin PCI Express Power Connector
