Series Name

OMN-S Series

Design
Screen Size

55"

Brightness

3000 nits

Contrast Ratio (Dynamic)

6,000:1

Viewing Angle (H/V)

178/178

Operation Hours

'24/7

General Feature

120Hz / 60Hz E-LED BLU

Pixel Pitch (mm)

0.630 x 0.630

Active Display Area (mm)

1209.6(H) x 680.4(V)

Brightness (Typ.)

3,000 / 1,000 cd/m2

Display Colors

8 bit - 16.7M

Color Gamut

72%

Orientation

Portrait

Response Time(G-to-G)

6ms(3,000nit), 10ms(1,000nit)

H-Scanning Frequency

15 ~ 135kHz (HDMI)

V-Scanning Frequency

24 ~ 75Hz (HDMI)

Maximum Pixel Frequency

594MHz (HDMI)

Connectivity
Input

RGB: N/A
VIDEO: HDMI 2.0 (2)
HDCP: HDCP 2.2
AUDIO: N/A
USB 2.0 (2)

Output

RBG: N/A
VIDEO: N/A
AUDIO: N/A
Power Out: N/A
USB: N/A

External Control

RS232C (In), RJ45 (In)

External Sensor

Detachable Type (IR, Ambient)

Power
Power Supply

AC 100 - 240 V, 50/60 Hz

Power Consumption (Typical/Max)

"Typical: 357 ? IEC 62087 measurement standard Max: 500"

General Feature

Internal

BTU (Max)

1705

Sleep Mode

less than 1W

Power Consumption (Off Mode)

less than 0.5W

Environmental Conditions
Operating Temperature

0?~ 40?

Operating Humidity

10~80%

Features
Key

Dual Display
Slim design Semi-Outdoor
Built-in MagicInfo Player S7, SSSP 7.0

Special

IP 5X rated, Polarized Sun Glasses Viewable in any direction, Portrait Installation Support, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), WiFi Module Embedded (2ea, one per each display)

24/7 Operation

Yes

Internal Player
Processor

Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory

L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB

Clock Speed

1.7GHz

Main Memory Interface

2.5GB
LPDDR4 1.5GHz 64bit

Graphics

Graphic resolution : 1920x1080
Output resolution : 1920x1080
- Supports OpenGL ES

Storage

8GB
(3.88GB Occupied by O/S, 4.12GB Available)

Multimedia

Video Decoder FHD MFD : VP8, H.264, AVS+(60Hz)UHD MFD : HEVC, H.264, VP95K HEVC Decoder, SHVC(ATSC3.0)AVS2.0 HEVC / AVS2.0 1xUHD120p (DP_NR off, FRC bypass) Audio Decoder - AC3 (DD), MPEG

IO Ports

USB 2.0

Operating System

Tizen 5.0 (VDLinux)

Dimensions
Without Stand (W x H x D)

726.8 x 1299 x 69.5 mm

Packaging (W x H x D)

940 x 1466 x 367 mm

Bezel Width

22.8 (even)

Weight
Product Weight

42kg

Package Weight

52kg

Accessories
Included in Box

Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, IR, Ambient sensor

Certifications
Safety

60950-1

EMC

Class A

Environment

802.1x(WPA2 Enterprise)
