Technical Specifications
Overview
Dimensions
93 x 62 x 35 mm (3.7 x 2.4 x 1.4")
Weight
156 g (5.5 oz)
Power Cable
Included
Output Voltage
48V DC @ 0.65A
Rated Voltage
100–240V AC at 50/60Hz
LAN Activity Indicator
No
Gigabit LAN Port
Yes
Remote Reset Capability
No
Reset Button
No
2-pair Powering
Pins 4, 5 (+) and 7, 8 (-)
AC Connector
IEC-320 C6
Clamping Protection
11V Data, 60V power
Data In / PoE
RJ45 Shielded Socket
Input Current
0.75A Max.
Inrush Current
<100A peak at 26°C
Efficiency
87%
Switching Frequency
70 kHz Max.
Output Ripple
1% Max.
Line Regulation
? 3%
Load Regulation
? 5%
Max. Surge Discharge
1500A (8/20 µs) power
Peak Pulse Current
36A (10/1000 µs) data
Response Time
<1 ns
Shunt Capacitance
<5 pF data
Surge Protection
Difference and common mode
Ambient Storage Temperature
-30 to 70°C (-22 to 158° F)
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Operating Humidity
10 to 95% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC, UL, CCC
