Technical Specifications
Overview
Dimensions
442.4 x 43.7 x 400 mm
(17.4 x 1.7 x 15.8")
UniFi Application Suite
Network
Yes
Managed UniFi Devices
2,250+
Simultaneous Users Connected
22,500+
Max. WAN Port Count
8
Default WAN Ports
(1) 100G QSFP28
(1) 25G SFP28
(1) 10 GbE RJ45
Port Layout
1 GbE RJ45
2
(1G/100M/10M)
10 GbE RJ45
8
(10G/5G/2.5G/1G/100M)
25G SFP28
4
(25G/10G/1G)
100G QSFP28
4
(100G/40G)
MGMT
1
(1G/100M/10M)
Console
1
IDS/IPS Throughput
79 Gbps
Capacity
SSL/TLS Inspection Concurrent Sessions
10,000
Concurrent Sessions
10 Million
New Sessions / Second
120,000
Form Factor
Rack mount (1U)
Redundancy
Shadow Mode (VRRP) Gateway Failover
(2) Hot-Swappable PSUs

Security
Stateful Firewall
Yes
Application-Aware Layer 7 Firewall
Yes
SSL Inspection & URL Filtering
Yes
DPI & Traffic Identification
Yes
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
Yes
Content Filtering
Yes
Intrusion Prevention (IPS/IDS)
Yes
Ad Blocking
Yes
IDS/IPS Signatures
95,000+ with CyberSecure Enterprise

VPN & SD-WAN
License-Free SD-WAN
Yes
Site-to-Site VPN
Site Magic
Yes
IPsec
Yes
OpenVPN
Yes
VPN Server
Identity Endpoint One-Click VPN
Yes
Teleport Zero-Configuration VPN
Yes
WireGuard
Yes
OpenVPN
Yes
L2TP
Yes
VPN Client
OpenVPN
Yes
WireGuard
Yes

Networking
Multi-WAN Load Balancing
Yes
Shadow Mode (VRRP) High Availability
Yes
LACP Port Aggregation
Yes
Dynamic Routing
OSPF
Yes
BGP
Yes
Advanced QoS
Yes
Multicast DNS (mDNS)
Yes
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)
Yes
Integrated RADIUS Server
Yes
RADIUS over TLS (RadSec)
Yes
Additional Internet Failover with UniFi LTE Backup
Yes
Internet Quality and Outage Reporting
Yes
MAC Address Table Size
130,000
Policy-based WAN and VPN Routing
Yes
Customizable DHCP Server
Yes
IPv6 ISP Support
Yes
IGMP Proxy
Yes
All Traffic Flows
Yes

Hardware
Max. Power Consumption
171W
Power Method
Universal AC input, 100–240V AC, 7.5A Max., 50/60 Hz
Power Supply
(2) Hot-Swappable AC/DC 550W PSU
Supported Voltage Range
100–240V AC
Heat Dissipation
585 BTU/hr
Processor
24-core ARM® v9 at 2.5 GHz
System Memory
32 GB
On-board Storage
Integrated 128 GB SSD
Weight
7.85 kg (17.31 lb)
Enclosure Material
Aluminium CNC, SGCC steel
LCM Display
1.3" touchscreen
Management
Ethernet
Bluetooth
LEDs
Ethernet
Yes
SFP28
Yes
QSFP28
Yes
Swappable Fan
Yes
CRPS
Yes
Button
(1) Factory reset
ESD/EMP Protection
Air: ± 8kV, contact: ± 4kV
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC

Software
Application Requirements
Mobile App
UniFi iOS™: Version 10.35.0 and later
UniFi Android™: Version 10.38.1 and later
