Technical Specifications
Overview
Dimensions
100.8 × 56 mm
(diameter 4 × 2.2")
IR Night Vision
20 m (65 ft)
Face Recognition
Yes
License Plate Recognition
Yes
Smart Detections (People, Vehicles, Animals)
Yes
Resolution
4K
Field of View
H: 109.9°, V: 56.7°, D: 134.1°
Audio
Two-way audio
Tamper Resistance
IK08
Mounting
Ceiling, Wall mount (Included)
Gang Box Mounting Plate, Arm, Camera Dual mount, Junction box (Optional)
UniFi Application Suite
Protect

Performance
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
Max. Frame Rate
30 FPS
Resolution
8MP 3840 x 2160 (16:9)
Optics
Sensor
1/1.8" 8MP
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter

Hardware
Max. Power Consumption
9W
Supported Voltage Range
37–57V DC
Power Method
PoE
Processor
Quad-core Arm® Cortex®-A53 based chip
Weight
254 g (9 oz)
Enclosure Material
Aluminum alloy, polycarbonate
Button
(1) Factory-reset
Cable
Cable Diameter
Max. 6.5 mm (0.26")
Ambient Operating Temperature
-20 to 40° C (-4 to 104° F)
Ambient Operating Humidity
0 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
