Key Features - Supports up to 6 GPUs 1. Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s 2. Up to 2TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 16 DIMM slots 3. 6 PCI-E 3.0 x16 slots, 1 PCI-E 3.0 x8 (in x16) slots 4. 8 Hot-swap 2.5" SAS/SATA drive bays, 2 Hot-swap 2.5" SAS/SATA/NVMe drive bays 5. 1 SIOM for flexible Networking 6. 5x 8cm heavy duty fans with optimal fan speed control 7. 2000W Redundant Power Supplies Platinum Level (94%) Product SKUs SYS-2029GP-TR SuperServer 2029GP-TR (Black) Motherboard Super X11DPG-SN Processor/Cache CPU Dual Socket P (LGA 3647) Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s Support CPU TDP 70-205W Cores Up to 28 Cores with Intel® HT Technology GPU Support Please refer to: Compatible GPU list System Memory Memory Capacity 16 DIMM slots Up to 2TB ECC 3DS LRDIMM, 2TB ECC RDIMM, DDR4 up to 2666MHz Memory Type 2666/2400/2133MHz ECC DDR4 SDRAM On-Board Devices Chipset Intel® C621 chipset SATA SATA3 (6Gbps) with RAID 0, 1, 5, 10 IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Graphics ASPEED AST2500 BMC Input / Output SATA 2 SATA3 (6Gbps) ports, 2 miniSAS ports LAN 1 RJ45 Dedicated IPMI LAN port USB 2 USB 3.0 ports (rear) Video 1 VGA port Serial Header 1 Fast UART 16550 header System BIOS BIOS Type AMI 256Mb SPI Flash ROM Management Software Intel® Node Manager IPMI 2.0 KVM with dedicated LAN SSM, SPM, SUM SuperDoctor® 5 Watch Dog Power Configurations ACPI / APM Power Management PC Health Monitoring CPU Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator FAN Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment Thermal Control for fan connectors Chassis Form Factor 2U Rackmount Model CSE-218GH-R2K03B Dimensions and Weight Height 3.5" (89mm) Width 17.2" (437mm) Depth 31" (787mm) Package 26.5" (H) x 11" (W) x 44.5" (D) Weight Net Weight: 39.5 lbs (17.9 kg) Gross Weight: 54 lbs (24.5 kg) Available Color Black Front Panel Buttons Power On/Off button System Reset button LEDs Power LED Hard drive activity LED Network activity LEDs System Overheat LED / Fan fail LED / UID LED Expansion Slots PCI-Express 6 PCI-E 3.0 x16 slots 1 PCI-E 3.0 x8 (in x16, LP) slot Drive Bays Hot-swap 10 Hot-swap 2.5" drive bays System Cooling Fans 5x 8cm Heavy duty fans with optimal fan speed control Power Supply 2000W 1U Redundant Power Supplies with PMBus Total Output Power 1000W/1800W/1980W/2000W Dimension (W x H x L) 73.5 x 40 x 265 mm Input 100-120Vac / 12.5-10.5A / 50-60Hz 200-220Vac / 10-9.5A / 50-60Hz 220-230Vac / 10-9.8A / 50-60Hz 230-240Vac / 10-9.8A / 50-60Hz 200-240Vac / 10-9.8A (UL/cUL only) 200-240Vdc / 10-9.1A (CCC only) +12V Max: 83.3A / Min: 0.1A (100-120Vac) Max: 150A / Min: 0.1A (200-220Vac) Max: 165A / Min: 0.1A (220-230Vac) Max: 166.7A / Min: 0.1A (230-240Vac) Max: 166.7A / Min: 0.1A (200-240Vac) (UL/cUL only) 12V SB Max: 3.5A / Min: 0A Output Type 25 Pairs Gold Finger Connector Certification Platinum Level Certified94%+ Platinum Level [ Test Report ] Operating Environment RoHS RoHS Compliant Environmental Spec. Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
